TS-SG-400
TECHNOSPACIO Elegent High Speed gate TS-SG-400 provide fast, reliable access control
of your building's entrance without compromising on security, while seamlessly blending in to the aesthetics
of the surrounding space.
It features for slim and stylish appearance. full body with clear tempered glass/lazer pattern acrylic
(optonal) adaptable to match any aesthetic requirements, while still retaining high level security features.
| Brand name |
TECHNOSPACIO |
| Motor type |
DC brushless motor |
| Cabinet Material |
SUS304+Side Glass panel+Top black acrylic lid |
| Passage width(mm) |
600-900mm |
| Rated Power |
50W |
| Flow rate |
30-40 persons/minute (pending on swing panel size) |
| Passage direction |
Single directional/Bi-directional |
| IR sensor(qty.) |
4 pairs(defaulted) |
| Power input |
AC100-240V,50/60HZ |
| Emergency signal |
Yes |
| Swing panel |
Acrylic/tempered (optional) |
| Working voltage |
50volt |
| Working humidity |
30%~95% |
| Working temperature |
-40℃~+70℃ |
| Compatibility |
Compatible to all recogntion methods available |
| Communication interface |
RS232/485 |
| Net Weight(kg) |
55 |
| Dimension(mm) |
1400*180*1000 |
